Product Specification |
System Parameters |
Battery capacity | 261kWh(0.5C)/270kWh(1C) | 418kwh/0.5C | 627kWh (0.5C) |
Dimensions(W*D*H) | 2928*1497*1655mm | 3205*1310*1550mm | 3205*1310*1550mm |
Weight | ≈3500kg | ≈5630kg | ≈6200kg |
Corrosion resistance grade | C4 | C4 | C4 |
Levels of protection | IP54 | IP54 | IP54 |
Operating ambient temperature | -10°C-50°C | -10°C-50°C | -10°C-50°C |
Work environment humidity | 0~95%RH | 0~95%RH | 0~95%RH |
Fire Protection Configuration | Airosol | Airosol | Airosol |
Temperature control method | Liquid cooling | Liquid cooling | Liquid cooling |
Charging method | Grid-connected AC/DC charging | Grid-connected AC/DC charging | Grid-connected AC/DC charging |
Discharge method | DC discharge/Off-grid AC discharge | DC discharge/Off-grid AC discharge | DC discharge/Off-grid AC discharge |
Type of shipping | Truckload/Trailer Roadbed Transport | Truckload/Trailer Roadbed Transport | Truckload/Trailer Roadbed Transport |
Fit chassis | Optional trailer hitch | Optional trailer hitch | Optional trailer hitch |
Charger System |
Is a charging gun included | 2 guns 160kW/2 guns 240kW | 2 guns 240 kW (Single gun 120kW) | 4 guns 320 kW |
Output Voltage Range | 200-1000VDC | 200-1000VDC | 200-1000VDC |
Battery Cluster Parameters |
Cell type | Lithium iron phosphate 314Ah/324Ah | Lithium iron phosphate 314Ah | Lithium iron phosphate 314Ah |
Cluster mode | 1P260S | 2P208S | 3P208S |
Voltage range | 728-949V | 582.4-759.2V | 582.4-759.2V |
AC-side Parameters |
Output rating | 105kW/250kW | 250kW | 375kW |
Rated output voltage | 230/400V | 400V | 400V |
Rated grid frequency(Hz) | 50/60 | 50/60 | 50/60 |
