| Model | MLP-51100R |
| Cell serial-parallel connection method | 16S1P |
| Nominal Voltage (V) | 51.2 |
| Nominal Capacity (Ah) | 100 |
| Nominal Energy (Wh) | 5120 |
| Working Voltage Range (V) | 40.5-54/43.2-57.6 |
| Maximum continuous charge current (A) | 100 |
| Maximum continuous discharge current (A) | 100 |
| Charging Cut-off Voltage (V) | 58.4 |
| Discharging Cut-off Voltage (V) | 43.2 |
| Communication Port | RS485, RS232, CAN |
| Charging Ambient Temperature (°C) | 0~45 |
| Discharging Ambient Temperature (°C) | -20~60 |
| Storage Ambient Temperature (°C) | 10~30 |
| Cycle Life (Cycles) | >6000, 25°C/77°F, 80% DOD |
| Protection Level | IP54 |
| Certification | CE/UN38.3 |
| Dimension (mm) | 490x445x133 |
| Weight (kg) | 45 |
| Warranty Period | 5 years |
